QW384-005-F
QUAWINTEC/OEM
8504401990
Shenzhen, China
L/C, T/T, D/P, Western Union, Paypal, Money Gram
white box/polybags/at your request outer package:carton
200PCS
50000 Pieces
Brand Name:QUAWIN
Model Number:QW384-005-F
Use:12S 36V 38.4V Lifepo4 battery pack
Type:Electric
Place of Origin:Guangdong China (Mainland)
Battery charger:automatic battery charger 43.8V
Color:Black
Shell Material:Plastic Shell(ABS+PC)
Input voltage:100-240VAC 50/60Hz
Output voltage:43.8V
Output current:0.5a(Max)
Output power:21.9W
Charge mode:CC—CV(Constant Current—Constant Voltage)
Output Connector:DC Jack,Waterproof Flat Jack,RCA,Multiple PIN,Micro USB,TYPE C,Small Alligator Clip,Ring Type Terminal,Air Jet Plug,customization
Packaging & Delivery:
Specifications:
12S 36V 38.4V Lifepo4 battery pack
Features:
• Charging mode:CC-CV(Constant Current-Constant Voltage)
• High efficiency and low power consumption
• Stabilized output and low noice
• Efficiency(at 100% load): >=85%
• Operating temperature:-20ºC ~ 45ºC
• Storage temperature:-40ºC ~ 85ºC
• Operating humidity:5%~90%RH
Specification:
• Input: 100-240VAC 50/60Hz
• Output: DC 43.8V
• Charging current: 0.5a(Max)
• Dimensions (mm): 115*47.2*34.3mm
• Weight: 250±5g(only body)
Safety protections:
• Over Voltage protection
• Short Circuit protection
• Polarity error protection
• Over power protection
LED Indicator:
The charger turn trickle-off charging mode if battery is full (1/10C), and indicate by LED:
• Charging:Red LED
• Battery Full:Green LED
Call us to know more details datasheet.
Typical Product Model | |||||
Model | Input Voltage | Battery Voltage | Charging Voltage | Charging Current | |
QW064-030-F | LiFePO4 | AC 100~264V | 6.4(2S) | 7.3 | 3 |
QW128-020-F | 12.8(4S) | 14.6 | 2 | ||
QW256-010-F | 25.6(8S) | 29.2 | 1 | ||
QW384-005-F | 38.4(12S) | 43.8 | 0.5 | ||
QW512-005-F | 51.2(16S) | 58.4 | 0.5 | ||
QW074-030-L | Lithium | 7.4(2S) | 8.4 | 3 | |
QW111-020-L | 11.1(3S) | 12.6 | 2 | ||
QW148-015-L | 14.8(4S) | 16.8 | 1.5 | ||
QW185-015-L | 18.5(5S) | 21 | 1.5 | ||
QW222-010-L | 22.2(6S) | 25.2 | 1 | ||
QW259-010-L | 25.9(7S) | 29.4 | 1 | ||
QW296-005-L | 29.6(8S) | 33.6 | 0.5 | ||
QW333-005-L | 33.3(9S) | 37.8 | 0.5 | ||
QW370-005-L | 37(10S) | 42 | 0.5 | ||
QW407-005-L | 40.7(11S) | 46.2 | 0.5 | ||
QW444-005-L | 44.4(12S) | 50.4 | 0.5 | ||
QW481-005-L | 48.1(13S) | 54.6 | 0.5 | ||
QW060-030-S | Lead Acid | 6(0.5S) | 7.35 | 3 | |
QW120-020-S | 12(1S) | 14.7 | 2 | ||
QW240-010-S | 24(2S) | 29.4 | 1 | ||
QW360-005-S | 36(3S) | 44.1 | 0.5 | ||
QW480-005-S | 48(4S) | 58.8 | 0.5 | ||
QW6-12-020-S | 6-12 | 7.35-14.7 | 2 |
