Availability: | |
---|---|
Quantity: | |
QW240-015-AI
QUAWINTEC/OEM
8504319000
Shenzhen, China
L/C, T/T, Western Union, Paypal, Money Gram
inner package: Industrial Packing Carton Size: 47*36.5*19 cm 50 pcs Per Carton
500PCS
500000 PCS/Month
Quick Detail:
Brand Name:QUAWIN/OEM
Model Number:QW240-015-AI
Use:Wall-mounted Adapter,Interchangeable plugs,Desktop Power Supplies,Type C charger, Quick Charger,Car Charger and Wireless Charger.
Type:Electric
Place of Origin:Guangdong China (Mainland)
Certificate:CE GS UL CB FCC SAA RCM PSE KC CCC Approvals
AC Plug:EU/US/UK/AU/CN standard
Color:Black/White
Input voltage:90-264VAC 47/63Hz
Output voltage:24V
Output current:1.5A
Output power:36W
Ripple & noise:240mV
Output Regulation:±5%
Energy Efficiency:LEVEL VI
Safeties Standard:60950/ 60335/ 61558/ 60065
Output connector:1.2m/1.5m/1.8m Wire
Operating Temperature:0ºC ~ +55ºC
Storage Temperature:-20ºC~+80%ºC
Dimension :97.3 * 45.3 * 32mm
Humidity:5~95%RH(non-condensing)
Primary to Secondary:50MΩ Min
Ripple and Noise:100mVp-p Max
Packaging & Delivery :
inner package: Industrial Packing Carton Size: 47*36.5*19 cm 50 pcs Per Carton
(Customized Packing To Be Acceptable)
Delivery Detail:sample within 7 work days,15~35 days for bulk order
Safety protections:
• Over Voltage protection
• Short Circuit protection
• Input protection
• Compliance with ROHS requirements
Typical model | Output Voltage | Output Current | Ripple & noise | Efficiency |
QW050-050-AI | 5V | 5000mA | 50mV | VI |
QW060-050-AI | 6V | 5000mA | 60mV | |
QW090-050-AI | 9V | 5000mA | 90mV | |
QW120-030-AI | 12V | 3000mA | 120mV | |
QW120-040-AI | 12V | 4000mA | 120mV | |
QW150-030-AI | 15V | 3000mA | 150mV | |
QW180-020-AI | 18V | 2000mA | 180mV | |
QW240-015-AI | 24V | 1500mA | 240mV | |
QW240-020-AI | 24V | 2000mA | 240mV |
