Factory Direct Sale 42V 8a 360W charger for 10S 36V 37V Li-ion/Lithium Polymer battery with CANBUS communication protocol

Model:QW370-080-LC
Input voltage:100-240VAC 50/60Hz
Output voltage:42V
Output current:8a(Max)
Dimensions (mm): 204*100*55

Availability:

Quantity:


Inquire Add to Basket

Model: QW370-080-LC
Brand: QUAWINTEC/OEM
Code: 8504401990
Port: Shenzhen, China
Payment Terms: L/C, T/T, D/P, Western Union, Paypal, Money Gram
Transport Package: white box/polybags/at your request outer package:carton
Min. Order: 500PCS
production: 50000 Pieces

Product Description

Quick Detail:

Brand Name:QUAWIN

Model Number:QW370-080-LC

Use:10S 36V 37V Li-ion or Li-polymer battery pack

Type:Electric

Place of Origin:Guangdong China (Mainland)

Battery charger:automatic battery charger 42V

Color:Black/Silver

Shell Material:Aluminium alloy

Additional features:CANBUS communication protocol

Input voltage:100-240VAC 50/60Hz with PFC

Output voltage:42V

Output current:8a(Max)

Output power:336W

Charge mode:CC—CV(Constant Current—Constant Voltage)

Output Connector:Crocodile clip,aviation connector,XLR,Ring terminal,Anderson connector,customization

Packaging & Delivery :

12pcs/Carton
Carton size: 535*315*280mm
Delivery Detail:sample within 7 work days,15~25 days for bulk order

Specifications:
10S 36V 37V Li-ion or Lithium Polymer battery PACK

Features:
• Charging mode:CC-CV(Constant Current-Constant Voltage)
• High efficiency and low power consumption
• Stabilized output and low noice
• Efficiency(at 100% load): >=90%
• Operating temperature:-20ºC ~ 45ºC
• Storage temperature:-40ºC ~ 85ºC
• Operating humidity:5%~90%RH

Specification:
• Input: 100-240VAC 50/60Hz with PFC
• Output: DC 42V
• Charging current: 8a(Max)
• Dimensions (mm): 204*100*55
• Weight: 1600g(only body)

Safety protections:
• Over Voltage protection
• Short Circuit protection
• Polarity error protection
• Over power protection

LED Indicator:
Waiting Mode:LED(GREEN) ON
Charging Mode:LED(BLUE) FLASH
Full Charged Mode:LED(GREEN) ON
Charge Error Mode:LED(RED) FLASH

Call us to know more details datasheet.

(A Typical Model)
Model		Input Voltage(V)	Battery Voltage(V)	Charging Voltage(V)	Charging Current(A)
QW128-200-FC	(LiFePO4)	AC 100~264V	12.8(4S)	14.6	20
QW256-120-FC			25.6(8S)	29.2	12
QW384-080-FC			38.4(12S)	43.8	8
QW512-060-FC			51.2(16S)	58.4	6
QW640-050-FC			64(20S)	73	5
QW768-040-FC			76.8(24S)	87.6	4
QW148-200-LC	(Lithium)		14.8(4S)	16.8	20
QW259-120-LC			25.9(7S)	29.4	12
QW370-080-LC			37(10S)	42	8
QW481-060-LC			48.1(13S)	54.6	6
QW629-050-LC			62.9(17S)	71.4	5
QW740-040-LC			74(20S)	84	4
