Chargers Adapters 7.2V 7.3V 3A 24W AU/EU/UK/US Wall Charger for 2S 6V 6.4V 3A LFP LiFePO4 LiFePO 4 battery charger

Share to:

Chargers Adapters 7.2V 7.3V 3A 24W AU/EU/UK/US Wall Charger for 2S 6V 6.4V 3A LFP LiFePO4 LiFePO 4 battery charger

Model:QW064-030-F
Input voltage:100-240VAC 50/60Hz
Output voltage:7.3V
Output current:3a(Max)
Dimensions (mm): 86*48*30.3

Availability:

Quantity:



Inquire Add to Basket

Model:
QW064-030-F
Brand:
QUAWINTEC/OEM
Code:
8504401990
Port:
Shenzhen, China
Payment Terms:
L/C, T/T, D/P, Western Union, Paypal, Money Gram
Transport Package:
white box/polybags/at your request outer package:carton
Min. Order:
500PCS
production:
50000 Pieces/month

Product Description

Quick Detail:

Brand Name:QUAWIN

Model Number:QW064-030-F

Use:2S 6V/6.4V Lifepo4 battery pack

Type:Electric

Place of Origin:Guangdong China (Mainland)

Battery charger:automatic battery charger 7.3V

Color:Black

Shell Material:Plastic Shell(ABS+PC)

Input voltage:100-240VAC 50/60Hz

Output voltage:7.3V

Output current:3a(Max)

Output power:21.9W

Charge mode:CC—CV(Constant Current—Constant Voltage)

Output Connector:DC Jack,Waterproof Flat Jack,RCA,Multiple PIN,Micro USB,TYPE C,Small Alligator Clip,Ring Type Terminal,Air Jet Plug,Audio frequency connector,customization

Packaging & Delivery:

150pcs/Carton
Carton size:618*378*273mm
Delivery Detail:sample within 7 work days,15~25 days for bulk order

Specifications:
2S 6V/6.4V Lifepo4 battery pack

Features:
• Charging mode:CC-CV(Constant Current-Constant Voltage)
  • High efficiency and low power consumption
  • Stabilized output and low noice
  • Efficiency(at 100% load): >=85%
  • Operating temperature:-20ºC ~ 45ºC
  • Storage temperature:-40ºC ~ 85ºC
  • Operating humidity:5%~90%RH

Specification:
• Input: 100-240VAC 50/60Hz
• Output: DC 7.3V
• Charging current: 3a(Max)
• Dimensions (mm): 86*48*30.3mm
• Weight: 120±5g(only body)

Safety protections:
• Over Voltage protection
• Short Circuit protection
• Polarity error protection
• Over power protection

LED Indicator:
The charger turn trickle-off charging mode if battery is full (1/10C), and indicate by LED:
• Charging:Red LED
• Battery Full:Green LED

Call us to know more details datasheet.

Typical Product Model
Model		Input Voltage(V)	Battery Voltage(V)	Charging Voltage(V)	Charging Current(A)
QW032-030-F	LiFePO4	AC 100~264V	3.2(1S)	3.65	3
QW064-030-F			6.4(2S)	7.3	3
QW128-015-F			12.8(4S)	14.6	1.5
QW256-005-F			25.6(8S)	29.2	0.5
QW037-030-L	Lithium		3.7(1S)	4.2	3
QW074-020-L			7.4(2S)	8.4	2
QW148-015-L			14.8(4S)	16.8	1.5
QW259-005-L			25.9(7S)	29.4	0.5
QW060-030-S	Lead Acid		6(0.5S)	7.35	3
QW120-015-S			12(1S)	14.7	1.5
QW240-005-S			24(2S)	29.4	0.5
