AU EU UK US 24W Wall Charger 21V 1a Smart Chargers for 5S 18V 18.5V lithium ion batteries Electric Scooter Toy Robots battery Pack

Model:QW185-010-L
Input voltage:100-240VAC 50/60Hz
Output voltage:21V
Output current:1a(Max)
Dimensions (mm): 86*48*30.3

Availability:

Quantity:



Inquire Add to Basket

Model:
QW185-010-L
Brand:
QUAWINTEC/OEM
Code:
8504401990
Port:
Shenzhen, China
Payment Terms:
L/C, T/T, D/P, Western Union, Paypal, Money Gram
Transport Package:
white box/polybags/at your request outer package:carton
Min. Order:
200PCS
production:
50000 Pieces

Product Description

Quick Detail:
Brand Name:QUAWIN
Model Number:QW185-010-L
Use:5S 18V 18.5V Li-ion or Li-polymer battery pack
Type:Electric
Place of Origin:Guangdong China (Mainland)
Battery charger:automatic battery charger 21V
Color:Black
Shell Material:Plastic Shell(ABS+PC)
Input voltage:100-240VAC 50/60Hz
Output voltage:21V
Output current:1a(Max)
Output power:21W
Charge mode:CC-CV(Constant Current-Constant Voltage)
Output Connector:DC Jack,Waterproof Jack,RCA,Multiple PIN,Micro USB,TYPE C,Small Alligator Clip,SAE Plug, Ring Terminal,Air Jet Plug,Audio Connector,Customized

Packaging & Delivery:

100pcs/Carton
Carton size:503*275*385mm
Delivery Detail:sample within 7 work days,15~25 days for bulk order

Specifications:
5S 18V 18.5V Li-ion or Lithium Polymer battery PACK

Features:
• Charging mode:CC-CV(Constant Current-Constant Voltage)
• High efficiency and low power consumption
• Stabilized output and low noice
• Efficiency(at 100% load): >=85%
• Operating temperature:-20ºC ~ 45ºC
• Storage temperature:-40ºC ~ 85ºC
• Operating humidity:5%~90%RH

Specification:
• Input: 100-240VAC 50/60Hz
• Output: DC 21V
• Charging current: 1a(Max)
• Dimensions (mm): 86*48*30.3mm
• Weight: 120±5g(only body)

Safety protections:
• Over Voltage protection
• Short Circuit protection
• Polarity error protection
• Over power protection

LED Indicator:
The charger turn trickle-off charging mode if battery is full (1/10C), and indicate by LED:
• Charging:Red LED
• Battery Full:Green LED

Typical Product Model
Model		Input Voltage(V)	Battery Voltage(V)	Charging Voltage(V)	Charging Current(A)
QW032-030-F	LiFePO4	AC 100～264V	3.2(1S)	3.65	3
QW064-020-F			6.4(2S)	7.3	2
QW128-015-F			12.8(4S)	14.6	1.5
QW256-005-F			25.6(8S)	29.2	0.5
QW037-030-L	Lithium ion		3.7(1S)	4.2	3
QW074-020-L			7.4(2S)	8.4	2
QW148-015-L			14.8(4S)	16.8	1.5
QW259-005-L			25.9(7S)	29.4	0.5
QW060-030-S	Lead Acid		6(0.5S)	7.35	3
QW120-015-S			12(1S)	14.7	1.5
QW240-005-S			24(2S)	29.4	0.5
QW2.4-4.8-020-N	NiMh/NiCD		2.4-4.8(2-4S)	3~6	2
QW3.6-7.2-015-N			3.6-7.2(3-6S)	4.5-9	1.5
QW4.8-9.6-012-N			4.8-9.6(4-8S)	6-12	1.2
QW6-12-010-N			6-12(5-10S)	7.5-15	1
QW7.2-14.4-008-N			7.2-14.4(6-12S)	9-18	0.8
QW9.6-19.2-006-N			9.6-19.2(8-16S)	12-24	0.6
QW12-24-005-N			12-24(10-20S)	15-30	0.5
QW18-36-004-N			18-36(15-30S)	22.5-45	0.4
