| Quantity: | |
|---|---|
QW120-300-S
QUAWINTEC/OEM
8504401990
Shenzhen, China
L/C, T/T, D/P, Western Union, Paypal, Money Gram
white box/polybags/at your request outer package:carton
200PCS
50000 Pieces
Quick Detail:
Brand Name:QUAWIN
Model Number:QW120-300-S
Use:12V Lead-Acid Battery
Type:Electric
Place of Origin:Guangdong China (Mainland)
Battery charger:automatic battery charger 14.7V
Color:Black/Silver
Shell Material:Aluminium alloy
Input voltage:AC 180～264V 50/60Hz
Output voltage:14.7V
Output current:30a
Output power:441W
Efficiency:>=89%
Shock & Vibration:SAEJ1378 Standard
Charge mode:CC---CV---Float Charge
Output Connector:Crocodile clip,aviation connector,XLR,Ring terminal,Anderson connector,customization
Packaging & Delivery :
Specifications:
Portable fast SLA /AGM /VRLA /GEL charger 12V Lead-acid Battery charger
Features:
• Fully auto CC +CV(H)+CV(L) charging process,with MCU controller
• Constant big charging current for faster charging;
• automatically charging ending with Cut-Off output;
• Metal case with Fan Cooling
• It can charge any 12V SLA/VRLA/GEL/AGM battery with capacity 120-250Ah
Specification:
• Input: AC 180～264V 50/60Hz
• Output: DC 14.7V
• Charging current: 30a(Max)
• Dimensions (mm): 204*100*55
• Weight: 1500g(only body)
Safety protections:
• Over Voltage protection
• Short Circuit protection
• Polarity error protection
• Over power protection
LED Indicator:
Waiting Mode:LED(GREEN) ON
Charging Mode:LED(BLUE) FLASH
Full Charged Mode:LED(GREEN) ON
Charge Error Mode:LED(RED) FLASH
Call us to know more details datasheet.
| (A Typical Model) | |||||
| Model | Input Voltage(V) | Battery Voltage(V) | Charging Voltage(V) | Charging Current(A) | |
| QW128-300-F | (LiFePO4) | AC 180~264V | 12.8(4S) | 14.6 | 30 |
| QW256-300-F | 25.6(8S) | 29.2 | 30 | ||
| QW384-200-F | 38.4(12S) | 43.8 | 20 | ||
| QW512-150-F | 51.2(16S) | 58.4 | 15 | ||
| QW640-120-F | 64(20S) | 73 | 12 | ||
| QW768-100-F | 76.8(24S) | 87.6 | 10 | ||
| QW148-300-L | (Lithium) | 14.8(4S) | 16.8 | 30 | |
| QW259-300-L | 25.9(7S) | 29.4 | 30 | ||
| QW370-200-L | 37(10S) | 42 | 20 | ||
| QW481-150-L | 48.1(13S) | 54.6 | 15 | ||
| QW629-120-L | 62.9(17S) | 71.4 | 12 | ||
| QW740-100-L | 74(20S) | 84 | 10 | ||
| QW120-300-S | (Lead Acid) | 12(1S) | 14.7 | 30 | |
| QW240-300-S | 24(2S) | 29.4 | 30 | ||
| QW360-200-S | 36(3S) | 44.1 | 20 | ||
| QW480-150-S | 48(4S) | 58.8 | 15 | ||
| QW600-120-S | 60(5S) | 73.5 | 12 | ||
| QW720-100-S | 72(6S) | 88.2 | 10 | ||
Quick Detail:
Brand Name:QUAWIN
Model Number:QW120-300-S
Use:12V Lead-Acid Battery
Type:Electric
Place of Origin:Guangdong China (Mainland)
Battery charger:automatic battery charger 14.7V
Color:Black/Silver
Shell Material:Aluminium alloy
Input voltage:AC 180～264V 50/60Hz
Output voltage:14.7V
Output current:30a
Output power:441W
Efficiency:>=89%
Shock & Vibration:SAEJ1378 Standard
Charge mode:CC---CV---Float Charge
Output Connector:Crocodile clip,aviation connector,XLR,Ring terminal,Anderson connector,customization
Packaging & Delivery :
Specifications:
Portable fast SLA /AGM /VRLA /GEL charger 12V Lead-acid Battery charger
Features:
• Fully auto CC +CV(H)+CV(L) charging process,with MCU controller
• Constant big charging current for faster charging;
• automatically charging ending with Cut-Off output;
• Metal case with Fan Cooling
• It can charge any 12V SLA/VRLA/GEL/AGM battery with capacity 120-250Ah
Specification:
• Input: AC 180～264V 50/60Hz
• Output: DC 14.7V
• Charging current: 30a(Max)
• Dimensions (mm): 204*100*55
• Weight: 1500g(only body)
Safety protections:
• Over Voltage protection
• Short Circuit protection
• Polarity error protection
• Over power protection
LED Indicator:
Waiting Mode:LED(GREEN) ON
Charging Mode:LED(BLUE) FLASH
Full Charged Mode:LED(GREEN) ON
Charge Error Mode:LED(RED) FLASH
Call us to know more details datasheet.
| (A Typical Model) | |||||
| Model | Input Voltage(V) | Battery Voltage(V) | Charging Voltage(V) | Charging Current(A) | |
| QW128-300-F | (LiFePO4) | AC 180~264V | 12.8(4S) | 14.6 | 30 |
| QW256-300-F | 25.6(8S) | 29.2 | 30 | ||
| QW384-200-F | 38.4(12S) | 43.8 | 20 | ||
| QW512-150-F | 51.2(16S) | 58.4 | 15 | ||
| QW640-120-F | 64(20S) | 73 | 12 | ||
| QW768-100-F | 76.8(24S) | 87.6 | 10 | ||
| QW148-300-L | (Lithium) | 14.8(4S) | 16.8 | 30 | |
| QW259-300-L | 25.9(7S) | 29.4 | 30 | ||
| QW370-200-L | 37(10S) | 42 | 20 | ||
| QW481-150-L | 48.1(13S) | 54.6 | 15 | ||
| QW629-120-L | 62.9(17S) | 71.4 | 12 | ||
| QW740-100-L | 74(20S) | 84 | 10 | ||
| QW120-300-S | (Lead Acid) | 12(1S) | 14.7 | 30 | |
| QW240-300-S | 24(2S) | 29.4 | 30 | ||
| QW360-200-S | 36(3S) | 44.1 | 20 | ||
| QW480-150-S | 48(4S) | 58.8 | 15 | ||
| QW600-120-S | 60(5S) | 73.5 | 12 | ||
| QW720-100-S | 72(6S) | 88.2 | 10 | ||
