AC 220V Factory Direct Sale DC 57.6V 58.4V 15a 900W charger for 16S 48V 51.2V LiFePO4 battery pack

Model:QW512-150-F
Input voltage:AC 180~264V 50/60Hz
Output voltage:58.4V
Output current:15a(Max)
Dimensions (mm): 204*100*55
Availability:
Quantity:
  • QW512-150-F
  • QUAWINTEC/OEM
  • 8504401990
  • Shenzhen, China
  • L/C, T/T, D/P, Western Union, Paypal, Money Gram
  • white box/polybags/at your request outer package:carton
  • 500PCS
  • 50000 Pieces
Quick Detail:

Brand Name:QUAWIN

Model Number:QW512-150-F

Use:16S 48V/51.2V Lifepo4 battery pack

Type:Electric

Place of Origin:Guangdong China (Mainland)

Battery charger:automatic battery charger 58.4V

Color:Black/Silver

Shell Material:Aluminium alloy

Input voltage:AC 180~264V 50/60Hz

Output voltage:58.4V

Output current:15a(Max)

Output power:876W

Charge mode:CC—CV(Constant Current—Constant Voltage)

Output Connector:Crocodile clip,aviation connector,XLR,Ring terminal,Anderson connector,customization


Packaging & Delivery :

 12pcs/Carton
 Carton size: 535*315*280mm

 Delivery Detail:sample within 7 work days,15~25 days for bulk order


Specifications:
 16S 48V/51.2V Lifepo4 battery pack

Features:
 • Charging mode:CC-CV(Constant Current-Constant Voltage)
 • High efficiency and low power consumption
 • Stabilized output and low noice
 • Efficiency(at 100% load): >=90%
 • Operating temperature:-20ºC ~ 45ºC
 • Storage temperature:-40ºC ~ 85ºC
 • Operating humidity:5%~90%RH


Specification:
 • Input: AC180~264V 50/60Hz
 • Output: DC 58.4V
 • Charging current: 15a(Max)
 • Dimensions (mm): 204*100*55
 • Weight: 1500g(only body)


Safety protections:
 • Over Voltage protection
 • Short Circuit protection
 • Polarity error protection
 • Over power protection


LED Indicator:
 Waiting Mode:LED(GREEN)  ON
 Charging Mode:LED(BLUE)   FLASH
 Full Charged Mode:LED(GREEN)  ON
 Charge Error Mode:LED(RED)   FLASH


Call us to know more details datasheet.

(A Typical Model)
Model Input Voltage(V) Battery Voltage(V) Charging Voltage(V) Charging Current(A)
QW128-300-F (LiFePO4) AC 180~264V 12.8(4S) 14.6 30
QW256-300-F 25.6(8S) 29.2 30
QW384-200-F 38.4(12S) 43.8 20
QW512-150-F 51.2(16S) 58.4 15
QW640-120-F 64(20S) 73 12
QW768-100-F 76.8(24S) 87.6 10
QW148-300-L (Lithium) 14.8(4S) 16.8 30
QW259-300-L 25.9(7S) 29.4 30
QW370-200-L 37(10S) 42 20
QW481-150-L 48.1(13S) 54.6 15
QW629-120-L 62.9(17S) 71.4 12
QW740-100-L 74(20S) 84 10
QW120-300-S (Lead Acid) 12(1S) 14.7 30
QW240-300-S 24(2S) 29.4 30
QW360-200-S 36(3S) 44.1 20
QW480-150-S 48(4S) 58.8 15
QW600-120-S 60(5S) 73.5 12
QW720-100-S 72(6S) 88.2 10
