Home » Products » Lead Acid Battery Charger » 900W » 900W Special Charger 48V 15a for AGM VRLA GEL Lead Acid Batteries RVS Other Motorcycles Solar Energy System Battery Pack

900W Special Charger 48V 15a for AGM VRLA GEL Lead Acid Batteries RVS Other Motorcycles Solar Energy System Battery Pack

Share to:

900W Special Charger 48V 15a for AGM VRLA GEL Lead Acid Batteries RVS Other Motorcycles Solar Energy System Battery Pack

Model:QW480-150-SM
Input voltage:100-240VAC 50/60Hz
Output voltage:58.8V
Output current:15a(Max)
Dimensions (mm): 285*140*90

Availability:

Quantity:



Inquire Add to Basket

Model:
QW480-150-SM
Brand:
QUAWINTEC/OEM
Code:
8504401990
Port:
Shenzhen, China
Payment Terms:
L/C, T/T, D/P, Western Union, Paypal, Money Gram
Transport Package:
Corrugated box,EPE pearl cotton/according to your requirements
Min. Order:
200PCS
production:
5000000 Pieces/1 Year

Product Description

Quick Detail:

Brand Name:QUAWIN

Model Number:QW480-150-SM

Use:48V Lead-Acid Battery

Type:Electric

Place of Origin:Guangdong China (Mainland)

Battery charger:automatic battery charger 58.8V

Color:Black/Army green
Shell Material:Aluminium alloy
Output voltage:58.8V

Output current:15a

Output power:882W
Efficiency:≧92%
Special Process: Spray Three Proof Paint
Electromagnetic compatibility: meets the requirements of GJB
Operating temperature:-40℃ ~ 65℃
Reliability: MTBF≧3000H

Charge mode:CC---CV---Float Charge

Output Connector:Waterproof plug, Crocodile Clip, Aviation Connector, XLR, Ring terminal, Aviation Model plug, SAE Plug, Anderson Connector, Customized

Packaging & Delivery:

4pcs/Carton
Carton size: 475*422*375mm
Delivery Detail:sample within 10 work days,15~25 days for bulk order

Specifications:
Portable fast SLA /AGM /VRLA /GEL charger 48V Lead-acid Battery charger

Features:

• Fully auto CC +CV(H)+CV(L) charging process,with MCU controller

• Constant big charging current for faster charging;

• Automatically charging ending with Cut-Off output;

• Metal case with Fan Cooling

• It can be used in harsh environmental conditions, with electromagnetic capacitance, high precision of voltage regulation, rain proof, low temperature resistance and corrosion resistance.

• It can charge any 48V SLA/VRLA/GEL/AGM battery with capacity 60-120Ah

Specification:

• Input: 100-240VAC 50/60Hz with PFC

• Output: DC 58.8V

• Charging current: 15a(Max)

• Dimensions (mm): 285*140*90

• Weight: 2900±50g(only body)

Safety protections:

• Over current protection
• Over voltage protection
• Short circuit protection
• Reverse polarity protection
• Anti-revert current protection
• Anti-spark protection

LED Indicator:

The charger turn trickle-off charging mode if battery is full (1/10C), and indicate by LED:
Waiting Mode:LED(GREEN) ON
Charging Mode:LED(BLUE) FLASH
Full Charged Mode:LED(GREEN) ON
Charge Error Mode:LED(RED) FLASH

Typical Product Model
Model		Input Voltage(V)	Battery Voltage(V)	Charging Voltage(V)	Charging Current(A)
QW128-500-FM	LiFePO4	AC 100~264V	12.8(4S)	14.6	50
QW256-300-FM			25.6(8S)	29.2	30
QW384-200-FM			38.4(12S)	43.8	20
QW512-150-FM			51.2(16S)	58.4	15
QW640-120-FM			64(20S)	73	12
QW768-100-FM			76.8(24S)	87.6	10
QW111-500-LM	Lithium ion		11.1(3S)	12.6	50
QW148-500-LM			14.8(4S)	16.8	50
QW259-300-LM			25.9(7S)	29.4	30
QW370-200-LM			37(10S)	42	20
QW481-150-LM			48.1(13S)	54.6	15
QW629-120-LM			62.9(17S)	71.4	12
QW740-100-LM			74(20S)	84	10
QW120-500-SM	Lead Acid		12(1S)	14.7	50
QW240-300-SM			24(2S)	29.4	30
QW360-200-SM			36(3S)	44.1	20
QW480-150-SM			48(4S)	58.8	15
QW600-120-SM			60(5S)	73.5	12
QW720-100-SM			72(6S)	88.2	10
