Military-Quality Battery Charger 4S 12V 12.8V 25a 30a 600W LFP LiFePO4 LiFePO 4 Smart Charger DC 14.4V 14.6V 25a 30a with PFC

Brand Name:QUAWIN

Model Number:QW128-300-FM

Use:4S 12V/12.8V Lifepo4 battery pack

Type:Electric

Place of Origin:Guangdong China (Mainland)

Color:Black/Army green

Shell Material:Aluminium alloy

Input voltage:100-240VAC 50/60Hz with PFC

Output voltage:14.6V

Output current:30a(Max)

Output power:438W

Special Process: Spray Three Proof Paint

Electromagnetic compatibility: meets the requirements of GJB

Reliability: MTBF≧3000H

Optional features:The battery pack with super capacitor can be charged from 0V

Output Connector:Waterproof plug, Crocodile Clip, Aviation Connector, XLR, Ring terminal, Aviation Model plug, SAE Plug, Anderson Connector, Customized

Packaging & Delivery :

Specifications:
 4S 12V/12.8V Lifepo4 battery pack

Features:
 • Charging mode:CC-CV(Constant Current-Constant Voltage)
 • High efficiency and low power consumption
 • Stabilized output and low noice
 • Efficiency(at 100% load): >=90%
 • Operating temperature:-40ºC ~ 70ºC
 • Storage temperature:-40ºC ~ 85ºC
 • Operating humidity:5%~90%RH

Specification:
 • Input: 100-240VAC 50/60Hz with PFC
 • Output: DC 14.6V
 • Charging current: 30a(Max)
 • Dimensions (mm): 215*100*55
 • Weight: 1600±10g(only body)

Safety protections:

  • Over current protection

  • Over voltage protection

  • Short circuit protection

  • Reverse polarity protection

  • Anti- revert current protection

  • Anti-spark protection

LED Indicator:

The charger turn trickle-off charging mode if battery is full (1/10C), and indicate by LED:

  Waiting Mode:LED(GREEN)  ON

  Charging Mode:LED(BLUE)   FLASH

  Full Charged Mode:LED(GREEN)  ON

  Charge Error Mode:LED(RED)   FLASH

Call us to know more details datasheet.
