Availability: | |
---|---|
Quantity: | |
QW640-020-F
QUAWINTEC/OEM
8504401990
Shenzhen, China
L/C, T/T, D/P, Western Union, Paypal, Money Gram
white box/polybags/at your request outer package:carton
200PCS
50000 Pieces/month
Brand Name:QUAWIN
Model Number:QW640-020-F
Use:20S 60V/64V Lifepo4 battery pack
Type:Electric
Place of Origin:Guangdong China (Mainland)
Battery charger:automatic battery charger 73V
Color:Black
Shell Material:Plastic Shell(ABS+PC)
Input voltage:100-240VAC 50/60Hz
Output voltage:73V
Output current:2a(Max)
Output power:146W
Charge mode:CC—CV(Constant Current—Constant Voltage)
Output Connector:Waterproof plug, Crocodile Clip, Aviation Connector, XLR, Ring terminal, Aviation Model plug, SAE Plug, Anderson Connector, Customized
Packaging & Delivery:
Specifications:
20S 60V/64V Lifepo4 battery pack
Features:
• Charging mode:CC—CV(Constant Current—Constant Voltage)
• High efficiency and low power consumption
• Plastic housing with Fan Cooling
• Stabilized output and low noice
• Efficiency(at 100% load): ≧85%
• Operating temperature:-20℃ ~ 45℃
• Storage temperature:-40℃ ~ 85℃
• Operating humidity:5%~90%RH
Specification:
• Input: 100-240VAC 50/60Hz
• Output: DC 73V
• Charging current: 2a(Max)
• Dimensions (mm): 152.5*63*45mm
• Weight: 500±5g(only body)
Safety protections:
• Over Voltage protection
• Short Circuit protection
• Polarity error protection
• Over power protection
LED Indicator:
The charger turn trickle-off charging mode if battery is full (1/10C), and indicate by LED:
• Charging:Red LED
• Battery Full:Green LED
• Error: RED Light Flashing
Call us to know more details datasheet.
Typical Product Model | |||||
Model | Input Voltage (V) | Battery Voltage (V) | Charging Voltage (V) | Charging Current (A) | |
QW064-100-F | LiFePO4 | AC 100~264V | 6.4(2S) | 7.3 | 10 |
QW128-100-F | 12.8(4S) | 14.6 | 10 | ||
QW256-050-F | 25.6(8S) | 29.2 | 5 | ||
QW384-030-F | 38.4(12S) | 43.8 | 3 | ||
QW512-025-F | 51.2(16S) | 58.4 | 2.5 | ||
QW640-020-F | 64(20S) | 73 | 2 | ||
QW768-015-F | 76.8(24S) | 87.6 | 1.5 | ||
QW074-100-L | Lithium | 7.4(2S) | 8.4 | 10 | |
QW111-100-L | 11.1(3S) | 12.6 | 10 | ||
QW148-090-L | 14.8(4S) | 16.8 | 9 | ||
QW185-070-L | 18.5(5S) | 21 | 7 | ||
QW222-060-L | 22.2(6S) | 25.2 | 6 | ||
QW259-050-L | 25.9(7S) | 29.4 | 5 | ||
QW296-040-L | 29.6(8S) | 33.6 | 4 | ||
QW333-040-L | 33.3(9S) | 37.8 | 4 | ||
QW370-035-L | 37(10S) | 42 | 3.5 | ||
QW407-030-L | 40.7(11S) | 46.2 | 3 | ||
QW444-030-L | 44.4(12S) | 50.4 | 3 | ||
QW481-025-L | 48.1(13S) | 54.6 | 2.5 | ||
QW518-025-L | 51.8(14S) | 58.8 | 2.5 | ||
QW555-020-L | 55.5(15S) | 63 | 2 | ||
QW592-020-L | 59.2(16S) | 67.2 | 2 | ||
QW629-020-L | 62.9(17S) | 71.4 | 2 | ||
QW666-020-L | 66.6(18S) | 75.6 | 2 | ||
QW703-015-L | 70.3(19S) | 79.8 | 1.5 | ||
QW740-015-L | 74(20S) | 84 | 1.5 | ||
QW060-100-S | Lead Acid | 6(0.5S) | 7.35 | 10 | |
QW120-100-S | 12(1S) | 14.7 | 10 | ||
QW240-050-S | 24(2S) | 29.4 | 5 | ||
QW360-030-S | 36(3S) | 44.1 | 3 | ||
QW480-025-S | 48(4S) | 58.8 | 2.5 | ||
QW600-020-S | 60(5S) | 73.5 | 2 | ||
QW720-015-S | 72(6S) | 88.2 | 1.5 |
